400G QSFP-DD Optical Transceivers

SR4, DR4, XDR4, PLR4, FR4, LR4, ER4, 2x FR2, SR4.2, SR8, DR8, XDR8, PLR8, FR8, LR8, ER8, 2x FR4, 2x LR4

Home>Products>Optical Transceivers>200G/400G/800G

400G QSFP-DD

Pro-optics provides hyperscale data centers with a series of 400G QSFP-DD pluggable optical transceiver modules based on 50G/100G PAM4 technologies. These modules can cover the interconnection links within 70m to 150m over multimode fiber (MMF) or 500m to 40km over single-mode fiber (SMF).

Feastures

  • Hot-pluggable QSFP-DD form factor transceiver modules

  • Compliant with QSFP-DD MSA, CMIS and IEEE 802.3 specifications

  • 8x 50G PAM4 or 4x 100G PAM4 electrical interface

  • 8x 50G PAM4 or 4x 100G PAM4 optical interface

  • Data rate up to 425Gbps

  • 850nm VCSEL or 1310nm/CWDM/LWDM/nWDM DFB (DML or EML) transmitters and PIN or APD receivers

  • Reach up to 70m/100m/150m over MMF or 500m/2km/10km/30km/40km over SMF

  • Duplex LC or dual duplex LC or single MPO or dual MPO receptacle

  • Low power consumption

  • Built-in digital diagnostic functions

  • Case operating temperature range: 0°C to 70°C

  • 3.3V power supply voltage

  • RoHS compliant (lead free)

Applications

  • Hyperscale Data Center

  • High-Performance Computing

  • 5G Midhaul/Backhaul

  • Metro Telecommunication

Ordering Information

400G QSFP-DD with 4x 100G PAM4 Optical Interface

P/NDescriptionData RateWavelengthDistanceConnectorTemp.
POQD40SR4400G QSFP-DD SR44x100G, 400GbE850nm60m (OM3)
100m (OM4)		MPO-12C
POQD40DR4400G QSFP-DD DR44x100G, 400GbE1310nm500mMPO-12C
POQD40XDR4400G QSFP-DD XDR44x100G, 400GbE1310nm2kmMPO-12C
POQD40PLR4400G QSFP-DD PLR44x100G, 400GbE1310nm10kmMPO-12C
POQD40FR4400G QSFP-DD FR44x100G, 400GbECWDM2kmDuplex LCC
POQD40LR4400G QSFP-DD LR44x100G, 400GbECWDM10kmDuplex LCC
POQD40ER4400G QSFP-DD ER44x100G, 400GbEnWDM30kmDuplex LCC

400G QSFP-DD with 8x 50G PAM4 Optical Interface

P/NDescriptionData RateWavelengthDistanceConnectorTemp.
POQD40SR42400G QSFP-DD SR4.28x50G 400GbE850/910nm70m (OM3)
100m (OM4)
150m (OM5)		MPO-12C
POQD40SR8400G QSFP-DD SR88x50G 400GbE850nm70m (OM3)
100m (OM4)		MPO-16C
POQD40DR8400G QSFP-DD DR88x50G 400GbE1310nm500mMPO-16C
POQD40XDR8400G QSFP-DD XDR88x50G 400GbE1310nm2kmMPO-16C
POQD40PLR8400G QSFP-DD PLR88x50G 400GbE1310nm10kmMPO-16C
POQD402FR4-(x)400G QSFP-DD 2x FR42x200GbECWDM2kmDual Duplex LC
Dual CS		C
POQD402LR4-(x)400G QSFP-DD 2x LR42x200GbELAN-WDM10kmDual Duplex LC
Dual CS		C
POQD40FR8400G QSFP-DD FR8400GbELAN-WDM2kmDuplex LCC
POQD40LR8400G QSFP-DD LR8400GbELAN-WDM10kmDuplex LCC
POQD40ER8400G QSFP-DD ER8400GbELAN-WDM40kmDuplex LCC
