800G QSFP-DD Optical Transceivers

SR4, DR4, XDR4, PLR4, FR4, LR4, ER4, 2x FR2, SR4.2, SR8, DR8, XDR8, PLR8, FR8, LR8, ER8, 2x FR4, 2x LR4

Home>Products>Optical Transceivers>200G/400G/800G

800G QSFP-DD

Pro-optics provides hyperscale data centers with a series of 800G QSFP-DD pluggable optical transceiver modules based on 100G/200G PAM4 technologies. These modules can cover the interconnection links within 60m to 100m over multimode fiber (MMF) or 500m to 10km over single-mode fiber (SMF).

Feastures

  • Hot-pluggable QSFP-DD form factor transceiver modules

  • Compliant with QSFP-DD MSA, CMIS and IEEE 802.3 specifications

  • 8x 100G PAM4 electrical interface

  • 8x 100G PAM4 or 4x 200G PAM4 optical interface

  • Data rate up to 850Gbps

  • 850nm VCSEL or 1310nm/CWDM/LWDM DFB (DML or EML) transmitters and PIN or APD receivers

  • Reach up to 60m/100m over MMF or 500m/2km/10km over SMF

  • Duplex LC or dual duplex LC or single MPO or dual MPO receptacle

  • Low power consumption

  • Built-in digital diagnostic functions

  • Case operating temperature range: 0°C to 70°C

  • 3.3V power supply voltage

  • RoHS compliant (lead free)

Applications

  • Hyperscale Data Center

  • High-Performance Computing

Ordering Information

800G QSFP-DD with 4x 200G PAM4 Optical Interface

P/NDescriptionData RateWavelengthDistanceConnectorTemp.
POQD80DR4800G QSFP-DD DR44x200G, 800GbE1311nm500mMPO-12C
POQD802FR2-(x)800G QSFP-DD 2x FR24x200G, 2x400GbE1291/1311nm2kmDual Duplex LC
Dual CS		C
POQD80FR4800G QSFP-DD FR44x200G, 800GbECWDM2kmDuplex LCC

800G QSFP-DD with 8x 100G PAM4 Optical Interface

P/NDescriptionData RateWavelengthDistanceConnectorTemp.
POQD80DR8-(x)800G QSFP-DD DR88x100G 800GbE1310nm500mMPO-16
Dual MPO-12		C
POQD80XDR8-(x)800G QSFP-DD XDR88x100G 800GbE1310nm2kmMPO-16
Dual MPO-12		C
POQD80PLR8-(x)800G QSFP-DD PLR88x100G 800GbE1310nm10kmMPO-16
Dual MPO-12		C
POQD802FR4-(x)800G QSFP-DD 2x FR42x400GbECWDM2kmDual Duplex LC
Dual CS		C
POQD802LR4-(x)800G QSFP-DD 2x LR42x400GbECWDM10kmDual Duplex LC
Dual CS		C
POQD80FR8800G QSFP-DD FR8800GbEWDM2kmDuplex LCC
POQD80SR8800G QSFP-DD SR88x100G 800GbE850nm60m (OM3)
100m (OM4)		MPO-16C
POQD80SR42800G QSFP-DD SR4.28x100G 800GbE850/910nmTBDMPO-12C
